Production Process
A twelve-metre animal standing 2.2 m tall is a wall rather than a tower. From the queue it looks like something lying across the ground, and that is exactly why it works beside a ride: it does not compete with the track behind it.
The build is 12 m long, 1.6 m wide across the body, 2.2 m to the top of the skull. Long, wide and low, which changes the pad, the crate size and the movement programme.
Twelve metres lying low
Length buys presence at distances that height cannot reach. A 12 m animal is visible from the far end of a midway, and at 2.2 m it leaves the sightline to a coaster or a wheel untouched.
What it costs is a longer pad, a heavier middle section, and a crane lift that has to fit around ride operations. The 1.6 m body width also asks for a wider gate than the smaller predators, which is worth checking before the site plan is signed.
Beside a ride, not across it
Set the long axis parallel to the ride. Parallel keeps the animal's back below the horizon of the track, so guests in the queue still watch the train come over the top. Turned across the path, the same animal becomes a screen and the ride loses its most reliable photo moment.
Keep 1.2 m between the flank and the queue rail. That gap lets someone stop for a photo without holding the line, and it gives a technician room to open the cabinet without stepping into the queue.
Head at the entry, tail at the exit. The head goes at the entry end of the queue. People arrive with time to look and leave wanting to move, so an animal facing the exit gets a glance at the back of someone's head. The tail points away, into planting or a service yard, where the swing has room.
A floor mat 3 m before the head, with a 1.2 second delay, times the turn to the walk. A queue moves in bursts, and a proximity sensor on its own fires at everybody in the line at once; the mat gives one trigger per group and the head arrives as they draw level.
What the length changes
Neck, head turn, jaw, blink, tail sway, breathing and a forelimb twitch. On a 12 m body the tail is the group to watch: a few degrees at the base becomes a large movement at the tip, and the tip is what reaches the planting or the rail.
We reduce the tail angle on the long builds and keep the head turn as the main gesture. At 2.2 m the head sits near adult eye level, so a turn toward the queue reads at a distance where the tail is already out of frame.
Frame and skin over a long span
Q235 steel frame, rust-proofed, high-density foam body, silicone skin 5-7 mm, colour in translucent layers, rated from -25°C to 45°C at 110 V or 220 V. Across 12 m the frame carries more joints, and every joint is a place where the skin flexes.
Those flex points get checked at commissioning and written down, because the hips and shoulders are where a crack shows first if a joint is set too tight. Ride-side sites also bring vibration and dust, so the cabinet mounts on rubber isolators and sits on the far side from the track.
Delivery and anchoring
Five sections, crates 1.6 m wide, so a 2 m gate is the minimum and a 2.5 m opening is comfortable. The middle section is the crane lift; the tail sections go on a telehandler. Unload the base frame first and place it, then the mid-body, then out to the ends.
The pad runs about 13 m by 2.5 m, four anchor points on a poured pad. Bolt the middle two first and let the ends follow: a 12 m frame fixed at one end and pulled straight will not sit flat, and the error shows up in the tail sway.
Before you order
Send the ride layout, the queue route, the sightline you want to keep clear, the ground, and the hours when a crane can work. Amusement sites usually give a maintenance window rather than a day, and that window decides the assembly plan.
Three cases where this size is wrong. A narrow queue with a 1 m aisle, where 1.6 m of body has nowhere to sit. A gateway where the animal is meant to loom, since 2.2 m does not loom. And a position with no crane standing within 6 m of the pad, where the middle section cannot be landed without closing the ride.
Enquiry
Send the site plan with the ride and the queue marked, and the hours when a crane is allowed on the midway. If the animal sits inside the ride envelope, tell us the safety distances now rather than after the pad is poured. Price excludes freight, duty, certificates and installation.
