YKL-049 Industrial-Grade Animatronic Spinosaurus
A 16m×5.8m Dynamic Masterpiece with Carbon Fiber Frame & Medical-Grade Silicone Skin
16m Long, 5.8m Tall
Massive 16m×2.1m×5.8m dimensions with 85% scientific accuracy—validated by Jurassic Park France project.
Advanced Motion System
9 servo motors drive jaw (≥70°), eyelids (0.5Hz blink), neck (±30°), and tail (1.2m amplitude) with biomechanical precision.
Military-Grade Durability
IP65 rating ensures stable operation from -20°C to 50°C—built for extreme environments.
Dynamic Motion Capabilities
Precision-engineered movements that replicate natural spinosaurus behaviors
Powerful Jaw Movement
≥70° jaw opening with synchronized throat pulsing—creates realistic feeding behaviors.
Expressive Eye System
0.5Hz natural blinking + pupil dilation—enhances lifelike presence and emotional expression.
Flexible Neck Articulation
±30° horizontal sweep—simulates scanning and hunting movements with fluid motion.
Dynamic Tail Motion
1.2m amplitude tail swings—creates balanced swimming and walking simulations.
Technical Specifications
Physical Dimensions
16000±50mm (L) × 2100±30mm (W) × 5800±80mm (H)
Power Consumption
Standby: 0.8kW / Peak: 5kW
Motion Precision
Joint repeat positioning error ≤0.5°
Acoustic System
150dB low-frequency vibrator (10-200Hz customizable spectrum)
Operational Life
≥100,000 motion cycles with proper maintenance
Control System
Gigabit Ethernet redundant ring network (<5ms delay)
Professional Applications
Deployed in world-class venues for maximum impact and educational value
Theme Park Centerpiece
Main entrance landmark with 200m attraction radius—proven to increase visitor dwell time by 40+%.
Educational Museum Display
GB/T 30235-2013 compliant dynamic teaching aid for paleontology research and public education.
Immersive Performance Core
Central unit for cultural tourism shows—synchronizes with lighting and sound systems for spectacular effects.
Installation & Maintenance Guide
Professional deployment specifications for optimal performance and longevity
Foundation Requirements
Concrete base with ≥15kN/m² bearing capacity—3D load distribution diagrams provided.
Network Infrastructure
Gigabit Ethernet redundant ring network with<5ms latency for real-time control.
Maintenance Protocol
Quarterly inspections + annual hydraulic calibration (includes torque sensor verification).
Important Notice
Final presentation may vary due to material batch differences and on-site environmental factors.
Appearance and effects may differ slightly from promotional materials.
Specific technical parameters are subject to actual test reports.
Please contact us for accurate technical specifications and customized solutions.
