Animatronic Flying Tiger | Shan Hai Jing White Tiger | Theme Park Decor

Name: Animatronic Flying Tiger | Shan Hai Jing White Tiger | Theme Park Decor
Brand: Yes Dino
Price: 3700 USD
Availability: InStock
Rating: 4.6 (28 reviews)

SKU	YDZ-008
Product Name	Lifelike Animatronic Flying Tiger Model
Dimensions	Length: 10 meters, Height: 9 meters (including wings and base), Wingspan: 7 meters.
Key Movements	Open mouth roaring, flapping wings, shaking head, neck movement up and down, wagging tail, glowing eyes.
Customization	Design and Pose, Color, Size, Movements, Lighting Effects.
Control System	This Animatronic Flying Tiger Model embodies a mythical creature from folklore. Not only does it boast a realistic and awe-inspiring appearance, but it also performs various movements. Ideal for placement in scenic areas, theme parks, or themed restaurants, this model brings the illustrated character from the story to life using steel and silicone materials. The combination of these materials presents a grand visual spectacle for visitors, making it a standout feature in your project and quickly capturing the attention of tourists.
Applications	Cultural tourism activities, ancient culture publicity exhibitions, decorations for various all-night cities, theme parks, amusement parks, etc.

Add to Quote

Product Description

YDZ-008 Dynamic Bionic Flying Tiger

A Mythical Beast Brought to Life: Scientifically Engineered for Immersive Cultural Tourism & Entertainment

10m Long, 9m High, 7m Wingspan

Faithfully recreates the legendary Baihu (White Tiger) from the "Classic of Mountains and Seas" with a massive 10m body length, 9m height, and 7m wingspan (engineering tolerance: ±0.3m).

High-Strength Composite Skin

5mm triple-layer silicone rubber composite skin reinforced with carbon fiber ribs for wind resistance. Built on a robust Q345B structural steel frame.

All-Weather Performance

IP54 protection rating for reliable operation in temperatures from -20°C to 50°C, suitable for demanding outdoor installations.

Core Advantages

High-Fidelity Dynamic Simulation

6 groups of servo motors drive the wings (8 flaps per minute, ≥200kg load per wing), head (30° swing), tail (0.8m amplitude), and jaw (90° opening angle) in coordinated, lifelike motion.

Visual Enhancement & Durability

Eyes feature RGBW quad-color LED modules (2000 cd/m² brightness, programmable effects). Carbon fiber ribs embedded in the skin provide structural reinforcement, achieving wind resistance up to Grade 10.

Energy Efficiency Optimized

Idle power consumption ≤1.2kW, with peak power of 5.8kW in full-motion mode. Complies with GB 30255 energy efficiency standards.

Precision Mechatronics

Multi-axis linkage control system achieves a neck pitch angle of ±45° and high-simulation movement, meeting the stringent requirements for mythical creature embodiment in cultural tourism projects.

Applied Technologies

Advanced engineering for reliable, precise, and intelligent performance

Mechanical Drive

Harmonic reducer (backlash ≤1 arcmin) + ball screw pair (positioning accuracy ±0.05mm) ensures smooth and precise movement.

Intelligent Control

PLC master control + distributed I/O modules (response delay<50ms). Supports TCP/IP protocol for remote operation and programming.

Material & Craftsmanship

Food-grade liquid silicone (Shore hardness 40±2A) injection molding. Weathering resistance tested to ASTM G154 standard (5000 hours UV aging).

Power & Motion

380V three-phase asynchronous motors (3kW × 4) deliver robust power. The multi-axis system achieves 8 wing flaps per minute and complex, coordinated animations.

Technical Specifications

Physical Dimensions

Length: 10m, Height: 9m, Wingspan: 7m (Tolerance: ±0.3m)

Power System

380V three-phase power. Idle: ≤1.2kW, Peak: 5.8kW.

Control System

Siemens S7-1200 PLC master. Supports TCP/IP remote control and OTA firmware updates.

Construction Materials

Frame: Q345B steel + 6061 aluminum alloy joints. Skin: 5mm triple-layer silicone rubber composite.

Safety & Compliance

CE / ISO 13849 PLd certified. IP54 rated for dust and water resistance.

Environmental Operating Range

Temperature: -20°C to 50°C. Wind Resistance: Grade 10.

Application Scenarios

Designed for high-impact installations across cultural, commercial, and entertainment venues

Cultural Tourism Landmarks

Ideal as a centerpiece entrance installation for theme parks, with a proven daily interaction rate of >5,000 visitors.

Commercial & Exhibition Spaces

Creates dynamic scenery for immersive dining experiences (recommended viewing distance ≥15m) and serves as a core exhibit for museum "Classic of Mountains and Seas" special exhibitions, compatible with AR recognition systems.

Film & Media Production

Functions as a physical reference prop for virtual production on green screens, with a tracking positioning accuracy of 0.1mm.

Professional Application Guide

Expert setup and maintenance for optimal long-term performance

Installation Specification

Requires a pre-buried Φ300mm concrete foundation with a load-bearing capacity ≥15 tons. Leveling error must be ≤3‰.

Maintenance Cycle

Gearbox lubricant should be replaced every 2,000 operational hours (Mobil SHC 634 grease is recommended).

Content & System Updates

Supports OTA firmware upgrades and expandable sound effect libraries (maximum 32GB audio file storage).

Important Notice

The YDZ-008 is a customized high-end installation. Due to variations in manual sculpting and on-site installation environments, the final product's texture details and colors may have reasonable deviations from promotional materials (refer to the 3D confirmation draft for details). The actual visual/audio presentation may differ slightly. Final effects are subject to the signed technical specification document. For accurate specifications and project-specific details, please contact our technical team.
