Custom Bronze Hot Pot | Campfire Night | Flame-Free Safe

Name: Custom Bronze Hot Pot | Campfire Night | Flame-Free Safe
Brand: Yes Dino
Price: 1600 USD
Availability: InStock
Rating: 4.5 (24 reviews)

SKU	YDZ-011
Product Name	Bronze-Like Hot Pot Model
Dimensions	The bronze hot pot has a diameter of 1-1.2 meters, and the maximum width of the firewood is 1.5 meters.
Key Movements	Flame lighting effects, Steam effects inside the pot, Sound effects
Customization	Various lighting effects, various steam effects, or sound effects of flames burning.
Control System	The Bronze Hot Pot model is specifically designed for stage performances and gatherings. When the lights are lit, it looks like a real campfire, effectively enhancing the festive atmosphere. We can customize iron pot models with local characteristics, incorporating effects such as smoke and lighting. Worldwide shipping is available!
Applications	Campfire night gatherings, Scenic area events, Ethnic group gatherings, Places where open flames are not practical

Add to Quote

Product Description

YDZ-011 Custom Bronze Hot Pot Model

Modular Steel-Frame Simulated Fire Pit for Immersive Atmosphere Creation in Flame-Free Scenarios

Durable Modular Frame

Modular steel frame with 120×80mm primary beams, structurally optimized via thermal simulation for superior heat dissipation. Features a flame-retardant silicone coating (3mm thick).

Third-Party Certified

Certified to withstand continuous 8-hour medium-intensity lighting load (≤3000 lumens) in non-open-flame scenarios. Model diameter: 1-1.2m, max "log pile" width: 1.5m.

High-Performance Design

High-density flame-retardant foam (≥45kg/m³) carved with flame texture. Silicone surface reflectivity 85%, optical simulation error<15%. Static load capacity ≥500kg.

Core Advantages

Structural Stability

Q235 carbon steel skeleton with triangular reinforcement nodes ensures static load capacity ≥500kg and wind resistance up to Level 7 (wind speed 13.9-17.1m/s).

Realistic Simulation

High-density flame-retardant foam (density ≥45kg/m³) intricately carved with flame textures. Silicone cladding with 85% reflectivity achieves optical simulation error<15%.

Energy Efficiency

Dynamic LED light system consumes only 450W, achieving 60% energy savings compared to traditional flame-effect installations.

Intelligent Control

Equipped with a PLC programmable logic controller, supports DMX512 protocol for stage equipment synchronization with response latency<0.5 seconds.

Multi-Modal Special Effects Technology

A layered system creating a fully immersive fire, smoke, and sound experience

Flame Layer

RGBW four-color LED matrix (200 pcs/㎡) combined with a fog machine (output 0.3L/min) for dynamic, realistic flame effects.

Steam Layer

Food-grade glycerin atomization system with precise temperature control (±2°C accuracy) for realistic, safe steam/smoke simulation.

Sound Effect Layer

Dual-channel directional speakers with a frequency response range of 80Hz-18kHz deliver immersive crackling fire and ambient soundscapes.

Operational Resilience

Wide operating temperature range (-20℃ to 50℃) and IP65-rated lighting system ensure reliable performance in various environments.

Technical Specifications

Physical Dimensions & Structure

Model Diameter: 1-1.2m | Log Pile Width: Max 1.5m | Main Frame: Q235 Square Tube (2.5mm wall thickness)

Exterior Materials

Flame-retardant silicone cladding (Shore A hardness 40±5) over high-density flame-retardant foam (≥45kg/m³).

Lighting System

5050 SMD LEDs with IP65 protection rating. Dynamic LED system power: 450W.

Control & Connectivity

4x DMX512 channels + 2x dry contact inputs. PLC programmable controller with<0.5s response latency.

Environmental & Power Specs

Operating Temperature: -20℃~50℃ | Gross Weight: 280kg (including counterweight base) | Recommended independent circuit: 220V/10A.

Performance Ratings

Static Load Capacity: ≥500kg | Wind Resistance: Level 7 (13.9-17.1m/s) | Certified for 8-hour continuous operation under ≤3000 lumens load.

Application Scenarios

Versatile solution for creating safe, immersive fire atmospheres across industries

Cultural & Tourism Performances

Used in the live-action show "Silk Road" bonfire scene (Shaanxi case, 1200+ cumulative performances).

Commercial & Retail Spaces

Featured in shopping mall winter theme exhibitions (Shanghai Global Harbor case with 3000+ peak daily visitors).

Emergency & Safety Training

Approved for flame-free simulation in forest fire drill scenarios (tested to NFPA 1403 standard).

Professional Application Guide

Installation, operation, and maintenance specifications for optimal performance

Installation Specification

Foundation bearing capacity must be ≥150kPa. Ensure leveling accuracy within ≤3mm/m². Requires an independent power circuit (220V/10A) with grounding resistance<4Ω.

Maintenance Schedule

Clean optical lenses every 200 operational hours. Apply anti-UV spray coating to the silicone layer every 2 years to preserve material properties and appearance.

Operational Safety

Designed for flame-free environments. Do not expose to open flames or excessive heat sources beyond the specified operating temperature range (-20℃ to 50℃).

Important Notice

Final presentation effects may vary by ±10% due to ambient light interference and individual perception differences. The actual product may differ from promotional materials. For accurate technical information and final specifications, please contact us. All performance data is subject to final project confirmation and on-site acceptance.
