YKL-037 Life-Size Animatronic Triceratops Juvenile
A Scientifically Accurate, 1:1.2 Scale Replica for Immersive Paleontological Education & Interactive Experiences
1.8m Tall, 1:1.2 Scale Accuracy
Strictly based on Cretaceous fossil specimens—1.8 meters (±2cm) in height, 1:1.2 scale design. Features a 304 stainless steel frame and high-elasticity silicone skin (Shore A 25 hardness).
32 Dynamic Joints
Equipped with 32 sets of dynamic joints for lifelike, fluid movements. Ideal for creating immersive paleontological educational scenarios.
All-Weather Operation
IP54 splash-proof rating—operates reliably in temperatures from -10℃ to 40℃ and humidity ≤80% RH for consistent indoor/outdoor performance.
Advanced Motion & Sensory Capabilities
Engineered for interactive, responsive, and engaging encounters
Precise Head Motion
Head sweeps ±30° with 0.5° precision—enables realistic scanning and interaction behaviors.
Rhythmic Tail Movement
Natural tail swing at 0.2Hz frequency, enhancing the lifelike "juvenile" behavioral profile.
Quiet Operation
Advanced joint mechanics ensure operational noise remains below 35dB, preventing auditory distraction.
Immersive Audio-Visual
16-bit stereo sound chip (supports .wav customization) and LED eyes with adjustable color temperature (2700K-6500K).
Technical Specifications
Core Technology
Sensing & Control: 6 PIR sensors (detection 0.5-3m, response ≤0.1s), STM32 MCU for motion programming.
Power System: Japan-imported micro servo motors (0.18N·m torque, >100k cycles).
A/V Module: 16-bit stereo chip, customizable .wav sounds, LED eyes (2700K-6500K CCT).
Power System: Japan-imported micro servo motors (0.18N·m torque, >100k cycles).
A/V Module: 16-bit stereo chip, customizable .wav sounds, LED eyes (2700K-6500K CCT).
Physical Dimensions
H1800×W900×D1100mm (±20% customizable; factory default error ±20mm).
Power & Environment
AC 220V/50Hz, power ≤300W. Operating temperature -10℃~40℃, humidity ≤80% RH.
Construction & Weight
Frame: 304 Stainless Steel; Skin: High-elasticity Silicone (Shore A 25). Net weight: 85kg (includes counterweight base).
Ingress Protection
IP54 rating (splash-proof)—suitable for most indoor and sheltered outdoor environments.
Dynamic System
32 dynamic joints for fluid, programmable movements. Designed for interactive engagement.
Applications & Benefits
Proven to enhance engagement, education, and commercial appeal
Scientific Education
The National Museum of Natural History (China) reported a 40% increase in visitor dwell time compared to static models.
Theme Park & Entertainment
Deployed at Changzhou Dinosaur Park entrance, recording an average of 1,200 daily interaction triggers.
Commercial Attraction
Shanghai Global Harbor Christmas season reported a 22% increase in foot-traffic conversion (third-party verified).
Professional Application Guide
Expert recommendations for optimal deployment and maintenance
Exhibition Configuration
For optimal parent-offspring scene creation, maintain a distance ≥3m from an adult Triceratops model. Recommended ambient lighting: 300-500 lux.
Maintenance Cycle
Lubricate all dynamic joints every 200 operational hours (food-grade silicone grease included).
Interactive Optimization
During peak visitor hours, set an action interval ≥45 seconds to optimize energy consumption and component longevity.
Important Notice
Due to the nature of 3D scanning, modeling, and hand-painting processes, the actual skin texture of the product may have reasonable variations (see QC Report Appendix C for details). Final presentation effects may vary due to on-site lighting, spatial layout, and configuration parameters. Actual visual/audio presentation may have slight differences from promotional materials. Accurate color parameters and motion protocols are subject to final project confirmation. For precise specifications, please contact our engineering team.
