YAA-006 Outdoor Realistic Gorilla Animatronic
A High-Fidelity, Mechatronic Wildlife Exhibit for Immersive Cultural Tourism & Entertainment Experiences
2.5m Long, 4.5m Sitting Height
True-to-life gorilla proportions—2.5 meters (8.2 ft) in length, 4.5 meters (14.8 ft) sitting height (6 meters / 19.7 ft standing), with a robust Q235B steel frame supporting up to 5 tons.
Multi-Layer Composite Build
Steel skeleton + high-density foam (≥35kg/m³) muscle layer + food-grade silicone skin. Built for ≥8 years of outdoor durability.
Dynamic Expression System
Features 8+ lifelike motions including roar, blink, chest-beat, and optional smoke effect, driven by a high-precision multi-DOF transmission system.
Core Technologies & Motion Performance
Engineered with industrial precision for authentic gorilla behavior simulation
Structural Design
Finite Element Analysis (FEA) optimized steel joints ensure ≤3mm deformation under dynamic loads.
Bionic Craftsmanship
400°C precision iron for hair texture (120 strands/cm²). Silicone vacuum infusion (3-5mm thick) achieves skin elasticity (Shore A 25 hardness).
Drive System
Servo motors (torque ≥50N·m) + planetary reducers enable ≤0.5s response time and ±1° positioning accuracy.
Smart Control
PLC (stores 100 motion sequences) + IoT module for remote diagnostics. Compatible with sound/light triggers (e.g., auto-activation when visitors approach).
Technical Specifications
Dimensions
L2500mm × Sitting H4500mm (Standing H6000mm) × W2000mm
Motion Performance
Action Types: Roar (90-110dB SPL), Blink (0.5-2 times/min), Head Rotation (±60°), Neck Pitch (±45°), Chest-Beat (1-3 times/set), Optional Smoke Spray (50-200ml/actuation). Response Time ≤0.5s, Operational Noise ≤65dB @1m.
Power
AC220V±10%/50Hz, Rated Power ≤3kW (includes motors, control, and optional smoke module).
Materials
Frame: Q235B square tube welding (wall ≥3mm). Muscle Layer: High-Density Polyurethane Foam (35kg/m³). Skin: Food-Grade Liquid Silicone (tensile strength ≥8MPa). Hair: Heat-Resistant Nylon Filament (15-20mm length).
Environmental Rating
Outdoor IP54 (Dust & Water Resistant). Operating Temperature: -10°C to 40°C.
Control System
Programmable Logic Controller (PLC) with IoT connectivity for remote diagnostics and maintenance.
Application Scenarios
Designed for venues seeking immersive storytelling, education, and high visitor engagement
Themed Tourism
As an iconic entrance landmark for theme parks (e.g., "Guardian of the Canyon" scenes) or interactive primate education zones in wildlife parks.
Film & Media Production
Serves as a pre-visualization physical model for movies/TV shows (e.g., "King Kong" series) or as a dynamic prop for commercials.
Event & Exhibition
Creates immersive stage installations for music festivals (with light/smoke effects) or acts as a traffic-driving photo spot for city cultural tourism festivals.
Professional Installation & Maintenance Guide
Expert setup and upkeep for optimal performance and longevity
Foundation Requirements
Requires a C30 concrete foundation (3m×3m×0.5m, load-bearing ≥5 tons) with pre-embedded M20 anchor bolts for an anti-overturning coefficient ≥1.8.
Maintenance Schedule
Weekly: Clean silicone surface with neutral detergent + soft brush. Quarterly: Check and lubricate transmission gears (lithium-based grease). Annually: Calibrate sensor zero points.
Environmental & Programming Notes
Avoid prolonged exposure to pH
Important Notice
This product offers deep customization based on client requirements. Due to variations in material batches (e.g., silicone pigment adjustments), foundation levelness, and personalized motion programming, the final product's visual and performance characteristics (such as hair density, skin gloss) may differ slightly from descriptions. The on-site lighting, spatial layout, and configuration parameters can also affect the final presentation. For precise information, all dimensions, motion logic, and visual performance are subject to the final physical acceptance report. Please contact us for accurate specifications and customized technical white papers.
