Lifelike 8m Animatronic Mammoth | Realistic Fur | 6 Actions for Exhibits

Name: Lifelike 8m Animatronic Mammoth | Realistic Fur | 6 Actions for Exhibits
Brand: Yes Dino
Availability: InStock
Rating: 4.6 (21 reviews)

SKU	RAA-014
Product Name	Lifelike Animatronic Mammoth Model
Dimensions	The length of the curve is 11 meters and the height is 8 meters
Key Movements	Nose curled, head left and right, neck up and down, tail wagging, front feet moving, mouth opened to roar
Customization	Size, movement, color, sounds and lighting effects, etc.
Control System	This mammoth model stands at an astounding height of 8 meters, adopting a standing posture as if in the midst of striking its opponent. It can be seamlessly incorporated into your narrative, easily creating a tense combat atmosphere. With its realistic appearance, the model can simulate various mammoth movements and emit roaring sounds. It serves well for educational purposes, contributing to a captivating experience in prehistoric animal exhibitions.
Applications	Large animal exhibitions, ancient paleontology exhibitions, Ice Age animal exhibitions, theme parks, museums, etc.

Add to Quote

Product Description

RAA-014 Life-Size Animatronic Woolly Mammoth

A Paleontologically Accurate, Dynamic Replica for Immersive Educational & Entertainment Experiences

8m Tall, 11m Curved Length

Matches adult Woolly Mammoth proportions—8 meters (26.2ft) in height, 11 meters (36ft) in curved length, with 2.2-meter tusks, built on a robust Q235B steel frame.

Hyper-Realistic Bio-Fur

Imported yak-hair composite fur (0.08-0.12mm single-strand diameter, density 1200 strands/cm²)—simulates a real mammoth's winter coat with ≥92% tactile similarity (third-party verified).

All-Environment Operation

IP65 weather rating—withstands temperatures from -20°C to 40°C and wind resistance up to Grade 8 for reliable outdoor performance.

Precision in Every Detail

Paleontologist-Approved Anatomy

Based on 3D skeletal modeling of a real Siberian permafrost specimen (ID: M-2019), ensuring biomechanically accurate proportions and posture. Motion trajectory error is less than 2mm.

Six Core Dynamic Motions

Features trunk curl (0.5m radius), head rotation (±45°), neck pitch (±30°), tail swing (±60°), forelimb flexion (±30°), and 90° jaw opening synchronized with a powerful roar.

Advanced Motion Control

6-axis servo motors (±0.1° precision) driven by inverse kinematics algorithms for natural, fluid movements. Integrated Siemens S7-1200 PLC ensures precise control and DMX512 lighting synchronization.

Immersive Audio Environment

100W waterproof speaker system (50-200Hz frequency response) delivers deep, resonant roars. Includes 10+ Ice Age ambient soundscapes (e.g., wind, snow, herd calls) for full immersion.

Advanced Motion Capabilities

Engineered movements that bring the Woolly Mammoth to life

Expressive Trunk & Head

Trunk curls with a 0.5m radius. Head rotates ±45° (1Hz) and neck pitches ±30° (0.8Hz), simulating foraging and alert behaviors.

Dynamic Tail & Limbs

Tail swings ±60° (0.5-2Hz). Forelimbs flex ±30°, creating a balanced, walking-like motion sequence.

Synchronized Roar

90° jaw opening triggers a powerful 80-150Hz low-frequency roar, synchronized with body motions for dramatic impact.

Environmental Immersion

10+ pre-loaded Ice Age soundscapes enhance realism. Supports custom educational narration modules aligned with school curricula.

Technical Specifications

Physical Dimensions

Height: 8m, Curved Length: 11m, Tusk Length: 2.2m (customizable ±0.3m). Weight: approx. 6.5 tons (including steel frame).

Power System

AC380V, 15kW servo system. Standby power consumption ≤0.5kW.

Motion Range

Head rotation: ±45°, Neck pitch: ±30°, Tail swing: ±60°, Forelimb flexion: ±30°, Trunk curl radius: 0.5m, Jaw opening: 90°.

Construction Materials

Frame: Q235B steel (8mm wall thickness). Skin/Fur: Imported yak-hair composite (1200 strands/cm² density).

Control & Audio

Control: Siemens S7-1200 PLC with IoT module for remote diagnostics. Audio: 100W waterproof speaker (50-200Hz).

Lighting & Durability

RGBW LEDs (5000 cd/m² brightness, IP67). IP65 rated for all-weather operation, wind resistance Grade 8.

Applications & Benefits

Designed for venues seeking impact, education, and long-term value

Museum-Grade Education

Paleontologically accurate centerpiece for prehistoric exhibits. Pairs with AR systems to trigger 3D evolutionary tree animations, aligning with school curriculum points.

Theme Park Spectacle

Ideal for "Ice Age" immersive theaters. Includes 3 preset motion scripts (foraging/defense/mating) and supports dry ice fog effects for enhanced immersion.

Durable & Low-Maintenance

IP65 rating ensures all-season outdoor operation. Robust Q235B steel frame and electrostatic flocking for fur attachment guarantee longevity with minimal upkeep.

Professional Application Guide

Tailored to your venue—plus expert setup and integration advice

Museum Exhibition

Place as a central exhibit in prehistoric zones. Combine with Pleistocene tundra dioramas and arrange exhibits using the "Morphology-Behavior-Extinction" narrative logic. Activate dynamic demonstrations upon visitor approach.

Theme Park & Theater

Deploy as an interactive showpiece. Utilize 3 preset motion scripts (foraging/defense/mating) synchronized with lighting (DMX512) and environmental effects (e.g., dry ice fog) for maximum audience engagement.

Educational & Research Use

Integrate with AR systems for interactive learning—scanning the model triggers 3D evolutionary animations. Includes teacher operation manuals with motion programming tutorials. Ideal for science centers and public outreach events.

Application Scenarios

• Core exhibit for prehistoric ecology halls in National/Provincial Natural History Museums.

• Interactive centerpiece for "Ice Age" immersive theaters in theme parks.

• Dynamic teaching tool for outdoor STEM education bases in primary and secondary schools.

• Flagship exhibit for "Return to the Ice Age" touring exhibitions in cultural tourism sites.

• Demonstration model for public science outreach days at research institutions.

Important Notice

This product is developed based on real mammoth fossil data (referencing "Mammoth: The Giant Mammal of the Pleistocene" pp. 123-156) and modern bionic technology. Due to custom sizing, on-site installation conditions (ground load-bearing, temperature, humidity), and individual perception differences, the actual visual and performance effects may vary from descriptions and promotional materials. The final presentation may have slight differences. For accurate specifications, please refer to the final technical documentation and third-party test reports. Contact us for customized technical white papers and detailed project data.
